80BSF-M07530 AC Servo Motor | 220V | 750W | 2.39 N.m Rated Torque

Category: Tags:, , , , , , , , , , , , , , , , Brand:

Description

80BSF-M07530 is a high-performance AC servo motor engineered for precise motion control and demanding industrial automation applications. It operates at 220V supply and delivers 750W rated power with a rated speed of 3000 RPM for stable high-speed performance. The motor provides rated torque of 2.39 N.m and maximum momentary torque up to 7.17 N.m, ensuring strong dynamic response and load handling capability. With peak speed up to 5000 RPM and a high-resolution 17-bit encoder, it offers accurate positioning and smooth control. The IP65 protection grade and Class F insulation ensure reliable operation in harsh industrial environments.

Application:

  • CNC Machine Manufacturers
  • Automation Equipment Manufacturers
  • Robotics and Motion Control Systems
  • Packaging Machinery Industry
  • Printing and Converting Machines
  • Textile and Industrial Machinery
Product Specification
Parameter Specification
Model 80BSF-M07530
Type AC Servo Motor
Rated Voltage 220 V
Rated Power 750 W
Rated Current 3.8 A
Rated Speed 3000 RPM
Peak Speed 5000 RPM
Rated Torque 2.39 N.m
Max Momentary Torque 7.17 N.m
Max Momentary Current 11.4 A
Encoder 17-bit
Line-Line Resistance 1.8 Ω
Phase Q-axis Inductance 5.2 mH
Phase D-axis Inductance 3.8 mH
Counter Electromotive Force 37.3 V/1000 r/min
Torque Coefficient 0.63
Rotor Inertia 1.56 × 10⁻⁴ Kg·m²
Protection Grade IP65
Insulation Class F
Ambient Temperature -20°C to 50°C
Insulation Resistance 500V ≥20MΩ
Withstand Voltage 1500V 5s
Weight 2.08 kg
Product Downloads
Product Catalogue
2D Drawing
