Coolmay EX3S-8043B-24MRT | DC24V | Mixed Output | 12DI 12DO + 4AI 2AO + 100KHz Counter

Category: Tags:, , , , , , , , , , , , , , , Brand:

Description

The Coolmay EX3S-8043B-24MRT is a compact all-in-one touch screen controller designed for industrial automation systems requiring both digital and analog signal handling. It provides 12 digital inputs and 12 mixed outputs, combining transistor and relay output types for flexible field load control. The unit includes fixed 4-channel analog inputs and 2-channel analog outputs, supporting voltage and current signals for sensors, transmitters, and control devices. It supports high-speed counting up to 100KHz with conventional single-phase 6-channel and AB phase 2-channel capability. The controller is equipped with RS485 communication ports for both HMI and PLC connectivity, enabling stable integration into industrial networks and automation environments.

Application:

  • Machine Builders
  • Packaging Industry
  • Automation Industry
  • Material Handling Industry
  • Process Control Industry
  • Industrial Control Panel Industry
Product Specification
Parameter Specification
Model EX3S-8043B-24MRT
Brand Coolmay
Type Integrated Touch Screen Controller
Power Supply DC24V
Digital Inputs (DI) 12
Digital Outputs (DO) 12
Output Type Mixed (Relay + Transistor)
Analog Inputs (AD) Fixed 4 channels
Analog Outputs (DA) 2 channels
Analog Input Signal Type 2CH Voltage 0-10V + 2CH Current 0-20mA
Analog Output Signal Type 2CH Voltage 0-10V / Current 0-20mA
HMI Communication Port Comes with 1 RS485
PLC Communication Port Comes with 2 RS485
High-Speed Counting (Single-phase) Conventional 6-channel, 100KHz
High-Speed Counting (AB phase) Conventional 2-channel, 100KHz
