Product Specification
| Parameter | Specification |
|---|---|
| Model | EX3S-43C-24MR |
| Brand | Coolmay |
| Type | Integrated Touch Screen Controller |
| Power Supply | DC24V |
| Digital Inputs (DI) | 12 |
| Digital Outputs (DO) | 12 |
| Output Type | Relay (MR) |
| Max Relay Load | 2A per point |
| Relay Voltage Rating | 250VAC / 30VDC |
| Relay Mechanical Life | 10 million times |
| Relay Electrical Life | 100000 times |
| Analog Inputs (AD) | 4 (2 Voltage 0-10V, 2 Current 0-20mA) |
| Analog Outputs (DA) | 2 (1 Voltage 0-10V, 1 Current 0-20mA) |
| HMI Communication | 1 × RS232 |
| PLC Communication | 1 × RS232 + 1 × RS485 |
| High-Speed Counting (Single Phase) | 4-channel 200KHz |
| High-Speed Counting (AB Phase) | 4-channel 200KHz |
