Product Specification
| Parameter | Specification |
|---|---|
| Model | EX3S-43C-24MT |
| Brand | Coolmay |
| Type | Integrated Touch Screen Controller |
| Power Supply | DC24V |
| Digital Inputs (DI) | 12 |
| Digital Outputs (DO) | 12 |
| Output Type | Transistor (MT) |
| Max Transistor Load | 0.5A per point |
| Analog Inputs (AD) | 4 |
| Analog Input Signal Type | 2CH Voltage 0-10V + 2CH Current 0-20mA |
| Analog Outputs (DA) | 2 |
| Analog Output Signal Type | 1CH Voltage 0-10V + 1CH Current 0-20mA |
| HMI Communication | 1 × RS232 |
| PLC Communication | 1 × RS232 + 1 × RS485 |
| High-Speed Counting (Single Phase) | Conventional 4-channel, 200KHz |
| High-Speed Counting (AB Phase) | Conventional AB phase 4-channel, 200KHz |
| High-Speed Pulse Output | Conventional 4-channel Y0-Y3, 200KHz |
