Delta DOP-107EV Human Machine Interface

Delta DOP-107EV HMI | DC 24V | 7″ Capacitive Touch | Ethernet + Serial + USB

Categories:, Tags:, , , , , , , , , , , , , , , , Brand:

Description

The Delta DOP-107EV Human Machine Interface is a 7-inch industrial touchscreen panel from the DOP-100 E-Type series engineered for advanced operator interaction and visualization. It features an 800 × 480 TFT LCD display with 65,536 colors, offering clear and responsive graphical performance for industrial control applications. Powered by a Cortex-A8 processor along with 256 MB RAM and 256 MB ROM, it supports smooth execution of HMI applications and process monitoring. The interface includes Ethernet connectivity along with multiple serial COM and USB ports for flexible integration with PLCs and automation equipment. With IP65-rated front protection and robust industrial design, it is suited for diverse factory automation environments.

Application:

  • Machine Control & Monitoring
  • Packaging & Assembly Automation
  • Material Handling Systems
  • Process Control Panels
  • Factory Automation Interfaces
  • OEM Equipment Integration
Product Specification
Parameter Specification
Model DOP-107EV
Brand Delta
Series DOP-100 E-Type
Type Human Machine Interface
Display Size 7″ TFT LCD
Display Resolution 800 × 480 pixels
Display Colors 65,536
CPU Cortex-A8 800 MHz
RAM 256 MB
ROM 256 MB
Touch Type Capacitive Touch
Ethernet 1 × 10/100 Mbps
Serial Ports 2 × COM (configurable: RS-232/RS-485)
USB Ports 1 × USB Host, 1 × USB Client
Power Supply 24 V DC
Panel Protection IP65 / NEMA4
Operating Temperature 0 °C … 50 °C
Storage Temperature –20 °C … 60 °C
Mounting Panel Mount
