Product Specification
| Parameter | Specification |
|---|---|
| Model | A7Pro-EW |
| Series | A Series SmartLink HMI |
| Product Type | Intelligent HMI / Touch Panel |
| Display Size | 7″ |
| Display Resolution | 1024 × 600 (HD Full Viewing Angle) |
| Display Colours | 16 million |
| Touch Type | Capacitive multi-touch |
| Storage | 8 GB Flash |
| RAM | 1 GB |
| Ethernet Ports | 2 × 10/100 Base-T |
| Serial COM Ports | 3 × (RS-232/RS-485) |
| USB Ports | 2 × USB Host |
| Global 4G | Built-in (Global 4G connectivity) |
| Wireless | Yes (Wi-Fi/Wireless optional) |
| Audio | Built-in speaker & microphone |
| Intelligent Features | Remote access, cloud connectivity, video, voice, TTS, RFID/NFC |
| Power Supply | 24 V DC |
| Protection | IP65 front |
| Mounting | Panel mount |
| Dimensions (W × H × D) | ~193 × 120 × 32 mm |
| Cut-Out Size | ~187 × 114 mm |
| Housing | Aluminium alloy |
