Haiwell – A16XDT Digital I/O Module

Haiwell A16XDT Digital I/O Module | 24 V DC | 8 DI & 8 NPN Outputs | DIN-rail Expansion

Categories:, Tags:, , , , , , , , , , , , , , Brand:

Description

The Haiwell A16XDT is a DIN-rail mountable digital I/O expansion module from the A Series card-type PLC lineup, designed to extend the I/O capacity of compatible Haiwell PLC hosts. It provides 8 digital inputs and 8 transistor (NPN) outputs configurable for industrial signal integration, enabling flexible expansion of system I/O without additional host modules. Operating on a 24 V DC power supply, it is suitable for distributed signal acquisition and control tasks. With a compact footprint and plug-in connectivity, the module supports efficient wiring and installation in automation cabinets. It is ideal for system integrators, machine builders and industrial automation applications requiring modular I/O scalability.

Application:

  • Industrial Machine Automation
  • I/O Expansion in PLC Systems
  • Packaging & Material Handling Control
  • Process Control & Monitoring
  • OEM Control Panels & Distributed I/O Networks
Product Specification
Parameter Specification
Model A16XDT
Series Haiwell A Series Card-Type PLC Modules
Product Type Digital I/O Expansion Module
Power Supply 24 V DC (Haiwell)
Digital Inputs 8 DI (24 V DC) (Haiwell)
Digital Outputs 8 DO, Transistor (NPN) (Haiwell)
Output Type Transistor (NPN) (Haiwell)
Power Consumption < 4.8 W (typical) (Link Automation)
Mounting DIN-rail / Card-type (Haiwell)
Dimensions (W × H × D) 25 × 95 × 65 mm (Haiwell)
Communication Connected via PLC bus interface (Haiwell)
Product Downloads
Product Catalogue
User Guide
